SW100-M

This trailer-mounted diesel engine pump truck is an efficient and portable emergency drainage device, featuring a compact design for easy towing and mobility, allowing single-person transportation and operation to significantly enhance flexibility.

Our high vacuum system has patent certification. High-performance Oil-circulated Vacuum System with a maximum vacuum of -0.099 MPa and 100 m³/h exhaust capacity. Build-in cooling system ensures stable operation without oil overheating. The air-water separator prevents water from entering the oil tank, maitaining efficiency.

Performance

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 200 m³/h
Max Head : 50 m
Suction Height : 9 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >20 kW
Speed : 1500-2000 rpm
Cooling Method : Water Cooled

Pump Parameters

Inlet : 4 inch
Outlet : 4 inch
Speed : 1800 rpm
Pump Case : Cast Iron
Impeller : Cast Iron / Stainless Steel
Shaft : Carbon Steel / Stainless Steel
Max Particle Size : 45 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
