SW200-H

This diesel engine water pump is designed for high-efficiency drainage. No manual priming is required—simply start the diesel engine with one button to begin operation. It is easy to use and can run dry for over 2 hours, high head to cope with more drainage situations.

Our high vacuum system has patent certification. High-performance Oil-circulated Vacuum System with a maximum vacuum of ​-0.099 MPa and ​100 m³/h exhaust capacity. Built-in ​cooling system ensures stable operation without oil overheating. The ​air-water separator prevents water from entering the oil tank, maintaining efficiency.

Performance

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 800 m³/h
Max Head : 200 m
Suction Height : >8.5 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >45 kW
Speed : 1500-2000 rpm
Cooling Method : Water Cooled or Air Cooled

Pump Parameters

Inlet : 8 inch
Outlet : 8 inch
Speed : 1500 – 1800 rpm
Pump Case : Cast Iron
Impeller : Cast Iron/Stainless Steel
Shaft : Carbon Steel/Stainless Steel
Max Particle Size : 76 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
