SW400-M

Ideal for heavy-duty applications with a maximum output of 3000 m³/hour, the pump combines robust power with user-friendly features, ensuring quick setup and effortless handling while maintaining high durability and reliability in demanding environments.

Our high vacuum system has patent certification. High-performance Oil-circulated Vacuum System with a maximum vacuum of ​-0.099 MPa and ​100 m³/h exhaust capacity. Built-in ​cooling system ensures stable operation without oil overheating. The ​air-water separator prevents water from entering the oil tank, maintaining efficiency.

Performance

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 3000 m³/h
Max Head : 30 m
Suction Height : 8 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >165 kW
Speed : 1500 rpm
Cooling Method : Water Cooled

Pump Parameters

Inlet : 16 inch
Outlet : 16 inch
Speed : 1500 rpm
Pump Case : Cast Iron
Impeller : Cast Iron/Stainless Steel
Shaft : Carbon Steel/Stainless Steel
Max Particle Size : 105 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
