SW350-M

The pump’s manifold system splits inlet/outlet ports into smaller, lighter-weight connections, making hose handling easier and reducing user effort. A vacuum-assisted system ensures strong suction, achieving a maximum lift height of 8 meters for tough water extraction tasks.

Our high vacuum system has patent certification. High-performance Oil-circulated Vacuum System with a maximum vacuum of ​-0.099 MPa and ​100 m³/h exhaust capacity. Built-in ​cooling system ensures stable operation without oil overheating. The ​air-water separator prevents water from entering the oil tank, maintaining efficiency.

Performance

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 2000 m³/h
Max Head : 35 m
Suction Height : 8 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >100 kW
Speed : 1500 rpm
Cooling Method : Water Cooled

Pump Parameters

Inlet : 14 inch
Outlet : 14 inch
Speed : 1500 rpm
Pump Case : Cast Iron
Impeller : Cast Iron/Stainless Steel
Shaft : Carbon Steel/Stainless Steel
Max Particle Size : 100 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
