SW300-H

With strong sewage handling ability, the pump can pass large particles easily without clogging. The high-performance vacuum-assisted system ensure strong water intake. The inlet and outlet can be adjusted to 8 inches as needed, and the two-inlet, two-outlet design makes the water pipes lighter and easier to handle.

Our high vacuum system has patent certification. High-performance Oil-circulated Vacuum System with a maximum vacuum of ​-0.099 MPa and ​100 m³/h exhaust capacity. Built-in ​cooling system ensures stable operation without oil overheating. The ​air-water separator prevents water from entering the oil tank, maintaining efficiency.

Performance

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 1300 m³/h
Max Head : 160 m
Suction Height : >8.5 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >450 kW
Speed : 2000 rpm
Cooling Method : Water Cooled

Pump Parameters

Inlet : 12 inch
Outlet : 12 inch
Speed : 2000 rpm
Pump Case : Cast Iron
Impeller : Cast Iron/Stainless Steel
Shaft : Carbon Steel/Stainless Steel
Max Particle Size : 85 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
