SW200-R

The SW200-R features an optional hydraulically driven crawler track system, allowing the pump to travel safely across uneven terrain. Wireless remote control operation enables precise positioning while keeping operators at a safe distance. The impeller allows smooth passage of large particles. Its operating speed range (1500-2000 rpm) ensures stable performance, with a maximum drainage capacity of 800 m³/h.

High-performance Oil-circulated Vacuum System has patent certification with a maximum vacuum of ​-0.099 MPa and ​100 m³/h exhaust capacity. Built-in ​cooling system ensures stable operation without oil overheating. The ​air-water separator prevents water from entering the oil tank, maintaining efficiency. The SW200-R features self propelled tracks and remote control opperation.

Performance

Crawler Mobility System

• Hydraulic crawler drive
• Wireless remote control
• 250 mm minimum ground clearance
• Variable speed operation
• Suitable for rough, soft and uneven terrain
• 30% (17°) climbing capability
• 360° zero-radius turning
• Sealed maintenance-free rollers and sprockets

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 800 m³/h
Max Head : 45 m
Suction Height : >8.5 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >45 kW
Speed : 1500-2000 rpm
Cooling Method : Water Cooled or Air Cooled

Pump Parameters

Inlet : 8 inch
Outlet : 8 inch
Speed : 1500 – 1800 rpm
Pump Case : Cast Iron
Impeller : Cast Iron/Stainless Steel
Shaft : Carbon Steel/Stainless Steel
Max Particle Size : 76 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
