SW350-H

Built for durability and user convenience, this pump combines power, smart design, and hassle-free operation—perfect for demanding environments. Upgrade to a pump that works harder, smarter, and longer!High head to cope with more drainage situations.

Our high vacuum system has patent certification. High-performance Oil-circulated Vacuum System with a maximum vacuum of ​-0.099 MPa and ​100 m³/h exhaust capacity. Built-in ​cooling system ensures stable operation without oil overheating. The ​air-water separator prevents water from entering the oil tank, maintaining efficiency.

Performance

Machine Performance

Type : Trailor Mounted, Stationery, Closed, Open Type
Max Flow : 2000 m³/h
Max Head : 120 m
Suction Height : 8 m

Diesel Engine Parameters

Brand Recommended : Cummins, Weichai, Baudouin, Deutz
Power : >550 kW
Speed : 1800 rpm
Cooling Method : Water Cooled

Pump Parameters

Inlet : 14 inch
Outlet : 14 inch
Speed : 1800 rpm
Pump Case : Cast Iron
Impeller : Cast Iron/Stainless Steel
Shaft : Carbon Steel/Stainless Steel
Max Particle Size : 100 mm

Accessories Available

Suction Pipe, Hose, Quick Connections, Strainers, Clamps
